PU8 Titan Tonearm
Absolute stability. Zero compromise.
The Audio Origami PU8 Titan is a zero-compromise tonearm, re-engineered with advanced materials to push vinyl playback to its absolute limit.
Building upon the proven architecture of our PU8 Reference tonearm, the PU8 Titan edition replaces stainless steel structural components with precision-machined Titanium, reducing the overall mass of the arm assembly by 40% while enhancing structural rigidity.
Titanium is expensive to source and notoriously difficult to machine, requiring specialised tooling, slower cutting cycles, and absolute precision, but its resonance management is second to none. Titanium has an exceptionally high strength-to-weight ratio and low internal acoustic Q, meaning it naturally dissipates energy rather than storing it. Acoustic energy travels through Titanium at extremely high velocity, and structural resonances are shifted far above the audible spectrum.
Furthermore, Titanium’s natural resistance to mechanical ringing effectively drains micro-vibrations directly away from the cartridge rather than reflecting them back down the cantilever. Despite the immense manufacturing challenges, the result justifies every extra step: a dramatically lower noise floor, unmatched structural rigidity, and pure, uncoloured energy transfer..
The PU8 Titan retains the precision gimbal assembly of the PU8 Reference for exceptional pivot stability, but pairs it with a solid Titanium headshell. This intentionally increases effective mass, creating the ideal mechanical match for demanding, low-compliance cartridges. Working in direct synergy with our constrained-layer carbon–aluminium armtube, Meta Material Arm Damping System, and anti-skate assembly, this architecture dissipates parasitic energy cleanly while preserving maximum transient speed and micro-detail.
While the 40% reduction in total mass makes the PU8 Titan far easier to set up and balance on delicate suspended turntables, it remains equally formidable on high-mass non-suspended designs.
By combining heightened structural rigidity and higher effective mass with an ultra-quiet mechanical environment, the new Audio Origami PU8 Titan unlocks unprecedented dynamics, rock-solid pitch stability, and effortless musical coherence. Designed without cost or manufacturing constraint, it serves as the ultimate interface for ultra-high-end turntables and modern, low-compliance cartridges.
PU8 Titan Tonearm unique features...
One of the fundamental challenges in tonearm design is controlling resonance while maintaining complete stability at the cartridge pivot. The PU8 Titan addresses these challenges through a zero-compromise selection of materials and advanced mechanical solutions.
Enhanced Material Damping
By replacing stainless steel with precision-machined, high-grade Titanium parts, overall arm assembly mass is reduced by 40% while structural rigidity is increased. This drains micro-vibrations away from the stylus without altering the arm’s precise mechanical balance.
Carbon-Aluminum Armtube
By bonding an inner aluminium core to an outer carbon-fibre sleeve, the PU8 Titan armtube is an exceptionally stiff, lightweight structure. This constrained-layer design minimizes energy storage, ensuring a exceptionally pure, uncolored signal reaches your phono stage.
Improved Anti-Skate Device
The PU8 Titan anti-skate mechanism delivers meticulous, frictionless bias control across the entire surface of the record. Relocated safely away from the cueing lever, it offers precise control alongside smooth, effortless operation.
Titanium Headshell
The new Titanium headshell elevates the tonearm’s effective mass providing the inertia necessary for low-compliance cartridges to operate at their absolute peak, resulting in superior tracking accuracy, dynamic impact, and pitch stability.
Meta Material Armtube Damping System V2
Our next-generation M.M.A.D.S. technology decouples the internal signal conductors from the armtube structure by effectively floating the internal wiring and damping standing waves within the arm assembly.
Designed for Low Compliance Cartridges
Engineered specifically for high-end, low-compliance cartridges, the PU8 Titan provides the ideal mechanical sink to unlock their maximum dynamic authority, tracking accuracy, and micro-detail.
PU8 Titan Tonearm Specifications...
| PU8 Tonearm | 9” / 9.45” | 12” |
|---|---|---|
| Effective Length | 9 inches or 9.45 inches | 12 inches |
| Effective Mass | Custom from 20g | Custom from 25g |
| Tonearm Type | Precision Gimbal | Precision Gimbal |
| Mount | Rega / Linn | Rega / Linn |
| Pivot Plate | Titanium | Titanium |
| Armtube | Constrained Layer Carbon Alloy | Constrained Layer Carbon Alloy |
| Armtube Damping | Meta Material | Meta Material |
| Headshell | Titanium | Titanium |
| Gimbal Housing | Titanium | Titanium |
| Bearings | Precision Race | Precision Race |
| VTA | Adjustable | Adjustable |
| Azimuth | Adjustable | Adjustable |
| Anti-Skate | Adjustable | Adjustable |
| Internal Wiring | Cardas | Cardas |
| Connection | Zavfino 5 pin DIN | Zavfino 5 pin DIN |
| Cartridge Tags | Zavfino Gold | Zavfino Gold |
| Counterweight | Threaded Steel | Threaded Steel |
| Colour | Satin Black | Satin Black |
| Packaging | Cardboard and Foam | Cardboard and Foam |
9" PU8 Titanium Tonearm
Available in 9 inch / 9.45 inch / 10 inch / 11inch / 12 inch
£9850
Audio Origami do not sell new tonearms directly, we only sell through our carefully chosen dealer network. This ensures that the tonearm you choose matches your cartridge and is perfectly set up.
Please note that if there is no dealer in your country or region, you can buy direct from Audio Origami.
PU8 Tonearm FAQs...
How does the PU8 Titan differ from the PU8 Reference?
While sharing the same foundational architecture, the PU8 Titan replaces stainless steel components with precision-machined Titanium and adds a solid Titanium headshell. This slashes overall arm mass by 40%—allowing it to set up effortlessly on suspended turntables—while strategically increasing the moment of inertia (effective mass) at the headshell to optimize performance with modern low-compliance cartridges.
From a material science perspective, Titanium features a significantly higher speed of sound transmission (≈6,070 m/sversus ≈5,000 m/s in steel) owing to its exceptional specific modulus (stiffness-to-density ratio). This higher velocity means mechanical energy generated by the stylus travels through the structure and dissipates far faster, pushing structural resonances safely outside the audible spectrum. The result is a noticeable leap in transient speed, precise leading-edge definition, and a slightly faster, exceptionally transparent, and neutral presentation.
Why is the PU8 Titanium more expensive than the PU8 Reference?
Titanium is a premium raw material, costing roughly 5 to 8 times more than stainless steel by weight. Beyond raw material expense, it is significantly more difficult to process, requiring specialised tooling, slower cutting speeds, and elevated machine wear.
We recognise there is a substantial price step between the PU8 Reference and the PU8 Titan, and for many systems, the Reference remains the ideal choice. However, for listeners demanding the absolute pinnacle of resonance control and effective mass performance, the PU8 Titan offers exceptional value when compared to other tonearms in it's class.
What are the sonic benefits of the Carbon-Aluminium composite armtube?
The Audio Origami PU8 Titan features a carbon-aluminium composite armtube utilising a constrained-layer design.
This architecture effectively disperses resonant frequencies, preventing mechanical energy from compromising the cartridge's tracking and sonic performance.
While maintaining exceptional rigidity and a low-mass profile, the armtube further shields the internal wiring from vibration, ensuring the integrity of the signal as it traverses the tonearm.
What is the Meta Material Arm Damping System (MMADS) V2, and how does it function?
M.M.A.D.S. is a specialised insert designed to decouple the internal wiring from the armtube.
By 'floating' the conductors within the arm, this structure prevents mechanical energy and resonance from degrading the delicate audio signal, thereby ensuring signal integrity.
Why does the PU8 Titan use a Delrin gimbal housing instead of traditional metal housings?
Delrin is a high-rigidity acetal homopolymer prized for its high internal damping, which effectively dissipates mechanical vibrations as thermal energy.
By utilising Delrin at the gimbal interface, the PU8 Titan isolates the precision bearings from parasitic resonance and provides a structurally damped housing for the armtube connection.
What is the range of customizable effective mass available for the PU8 Titan?
The effective mass of the Audio Origami PU8 Titan is fully customizable from 20g to 32g, to meet a client's specific cartridge requirements at the time of build. In its standard configuration, the PU8 Titan is optimised for cartridges with a compliance range of 5–15 units (10−6 cm/dyne). A comprehensive breakdown of compatible cartridge pairings is provided above.
Which cartridge compliance ratings (cu) are best suited for this tonearm?
In its standard configuration, the PU8 Titan is optimised for cartridges with a compliance range of 5–15 units (10−6 cm/dyne).
If you are unsure whether it will be suitable for you existing cartridge, please email:
stephen@audio-origami.co.uk
What internal wiring is used in the PU8 Titan, and are there different external cable options?
The PU8 Titan is standard-equipped with Cardas, a benchmark internal conductor known for its exceptional signal purity and low dielectric involvement. While we accommodate bespoke requests for alternative wiring, please note that Audio Origami cannot extend its warranty to third-party or customer-supplied cabling.
Which turntable mounting standards does the PU8 support?
The Audio Origami PU8 Titan is available in both Linn and Rega mounting configurations, ensuring seamless integration with the vast majority of high-end turntables.
This dual-format availability allows for near-universal compatibility across diverse armboard designs. If you require verification for a specific turntable model, please contact Stephen at stephen@audio-origami.co.uk for technical guidance.
What are the specific geometry differences between the 9-inch, 9.45-inch, and 12-inch versions?
Geometric parameters shift as tonearm length increases, necessitating precise calibration.
We recommend using a professional-grade instrument, such as the Dr. Feickert Protractor, to accurately establish the required pivot-to-spindle distance and ensure optimal cartridge alignment.
How is VTA (Vertical Tracking Angle) adjusted on the Audio Origami PU8 Titan?
Vertical Tracking Angle (VTA) is easily calibrated on the PU8 Titan by loosening two hex fasteners within the mounting collar.
This allows the base plate to be manually raised or lowered to the desired height.
The mechanism is designed for high efficiency, enabling precise height adjustments in under 30 seconds.
Does the PU8 Titan allow for independent Azimuth adjustment at the headshell or the pivot?
Azimuth is adjusted at the gimbal assembly by loosening two small hex fasteners on the Delrin bearing housing.
This allows for minute rotation of the armtube to ensure the stylus is perfectly perpendicular to the record surface.
We provide a precision headshell bubble level to establish an accurate baseline, though final micro-adjustments should be performed through critical listening to optimise stereo imaging and minimise crosstalk.
Is the PU8 Titan a modular design that can be upgraded if new components are released?
While the PU8 Titan will continue to undergo iterative refinements in the years ahead, we are committed to offering an upgrade path for existing owners. This policy ensures that your purchase remains a future-proof and sound investment, allowing your tonearm to evolve alongside our latest engineering advancements.
Where is the PU8 Titan tonearm designed and manufactured?
The Audio Origami PU8 Titan is designed, machined, and hand-assembled in Scotland.
To ensure the highest standards of mechanical performance, we source only a select few specialised components from outside the country: our precision-grade Japanese race bearings, high-purity internal conductors, and premium connectors.
How does a customer determine the correct effective mass for their specific cartridge before ordering?
While your authorised dealer is typically best positioned to assist with setup and compatibility, you may also refer to the Compatible Cartridge section above for technical data.
If you remain uncertain, please reach out to Stephen directly at stephen@audio-origami.co.uk for further guidance.
If there is no local dealer, can the PU8 Titan be purchased directly from Audio Origami?
While we strongly encourage customers to purchase through our authorised dealer network to ensure expert setup and ongoing support, we recognise that some regions are not yet served by a local dealership.
In these instances, you are welcome to purchase your PU8 Titan directly from Audio Origami. Please email stephen@audio-origami.co.uk for further assistance.
